ZS Series Circular Vibrating Sieve

Product Name:ZS Series Circular Vibrating Sieve

Keywords:ZS Series Circular Vibrating Sieve,Vibrating Sieve
Overview:The machine consist of hopper , vibrating chamber , couple and motor . There are eccentric wheel,rubber software, main shaft and shaft-bearing in the vibration chamber .The adjustable eccentric hammer

Description

General Descriptions
   The machine consist of hopper , vibrating chamber , couple and motor . There are eccentric wheel,rubber software, main shaft and shaft-bearing in the vibration chamber .The adjustable eccentric hammer is driven to the center line through the motor , cause centrifuged force under the state of unbalance and so that the materials from regular eddy . The amplitude of the hammer may be adjusted according to the property of material and the mesh screen.It is compact in structure, small in volume,thightness dust free, noise-free, high output,low in energy consumption, easy to move and easy to maintain.
ZS Series Circular Vibrating Sieve
Technical Parameter

Spec ZS-350 ZS-515 ZS-650 ZS-800 ZS-1000 ZS-1500
capacity(kg/h) 40-500 60-600 80-800 150-1200 300-2000 350-2800
meshes 12-1200 12-200 12-200 12-200 5-325 5-325
power(kw) 0.55 0.55 0.55 0.75 1.5 2.2
speed(rpm) 1380 1370 1370 1500 1500 1500
overall dimension(mm) 540×540×1060 710×710×1290 880×880×1350 1000×1000×1000 1100×1100×1200 1600×1600×1200
weight(kg) 100 180 250 300 350 400
